Schurter FMAC ECO Ultra-Compact Three-Phase Single-Stage EMC Filter
3-Phase Without Neutral | 480 VAC | 16–150 A | Aluminium Housing
Schurter FMAC ECO Three-Phase EMC Filter Overview
The Schurter FMAC ECO is a three-phase single-stage EMC filter for three-wire systems (without neutral), rated 16–150 A at 480 VAC from -25°C to 100°C. Its aluminium housing provides a more compact and lightweight package than the standard steel-housed FMAC family, making it well suited to installations where volume and weight are constrained. Industrial leakage only. Schurter now recommends the FMAC NEO for new designs.
-
Features
-
- Ultra-compact aluminium housing for reduced size and weight
- Three-phase, without neutral (3-wire)
- Industrial leakage only
- Screw clamp terminals
- IEC/UL 62368-1 application standard
- CE, UKCA, RoHS, China RoHS, REACH compliant
- Packaging: 1 pc
- Recommended replacement: FMAC NEO
-
Compatible Applications
For compact three-phase EMI filtering where housing volume and weight are restricted:
-
- Compact industrial drives and variable frequency drives
- Space-constrained machine tool cabinets
- Compact motor drive panels
- Light industrial power conditioning
- Embedded three-phase power electronics
FMAC ECO Technical Specifications
Technical specifications
| Parameter | Value |
|---|---|
| Rated Voltage | 480 VAC |
| Rated Current | 16–150 A |
| Frequency | 50/60 Hz |
| Filter Stages | 1 |
| Phase Configuration | 3-phase, without neutral |
| Operating Temperature | -25°C to 100°C |
| Housing Material | Aluminium |
| Terminal Type | Screw clamps |
| Leakage Current | Standard (industrial) |
| Application Standards | IEC/UL 62368-1 |
| Compliances | CE, UKCA, RoHS, China RoHS, REACH |
| Packaging | 1 pc |
| Recommended Replacement | FMAC NEO |
FMAC ECO Variants & Order Codes
|
Order No. |
Current (A) |
Housing |
Pkg |
|---|---|---|---|
|
FMAC-091C-1610 |
16 |
91C |
1 |
|
FMAC-091C-2510 |
25 |
91C |
1 |
|
FMAC-091D-3610 |
36 |
91D |
1 |
|
FMAC-091D-5010 |
50 |
91D |
1 |
|
FMAC-091D-5510 |
55 |
91D |
1 |
|
FMAC-091E-6410 |
64 |
91E |
1 |
|
FMAC-091T-8010 |
80 |
91T |
1 |
|
FMAC-091G-H110 |
110 |
91G |
1 |
|
FMAC-091G-H210 |
150 |
91G |
1 |
|
FMAC-3FSF-6410 |
64 |
3FSF |
1 |
Downloads & Documentation
FMAC ECO Datasheet
Buy Schurter FMAC ECO From the Official UK Distributor
Dalroad is the official UK distributor for Schurter. We hold reliable stock of their EMC filter range, and our team supports design engineers through component selection, system integration and supply planning for industrial power electronics, motor drive and power conversion applications. Submit an enquiry to book a call with our technical experts or request a sample.
